Tyri 1010LED24e-3500

The 1010 LED has been developed to meet or exceed the demanding operating requirements of construction, agricultural, forestry, mining, material handling, and other off-road equipment applications.  the 1010 LED has undergone rigorous environmental, electronic, and vibration/shock testing.
Model 1010LED24e-3500
  • Light Source: LEDs (Light emitting diodes)
  • Input Voltage : 9V - 32V
  • Life: 20,000 Hours
  • Light Output: 1,400 Lumens
  • Lens: Polycarbonate (standard) • Glass (Optional)
  • Connector/Power In: Deutsch DT06-2S
  • Mounting Bolt: M10
  • Mounting Bracket: 25mm, 30mm, 40mm
  • Approval: EMC (emission/susceptibility) compliant, reverse polarity & load dump protection, EN12895 Compliant
  • IP Protection • IP 67

For more information contact one of our Alliance Partners.
 Information contained herein can change at anytime
